| Maximum Working Height | 13.70 m |
| Maximum Platform Height | 11.70 m |
| Overall Width | 1.19 m |
| Stowed Length | 2.26 m |
| Stowed Height | 1.34 m |
| Platform Capacity | 350 kg |
| Gross Machine Weight | 3,221 kg |
| Gradeability | 25% |
| Tyres | solid non-marking |
| Overall Length | 3.36 m |
| Deck Extension | 0.91 m |
Scissor Lifts
Genie GS4047
- Reaches 13.7m (45 ft 1.5 in) of working height in less than 70 seconds
- Driveable at full height
- Compact width of 1.19 m (3 ft 11 in) width, footprint of just 2.44 m (8 ft) long, 1.88 m (6 ft 2 in) unit height with folded guardrails, allow the machine to go through stard double doorway
- Deck extension of 91 cm (3 ft) provides access above obstacles as well as a larger platform work area
- 25% gradeability useful for travelling up slopes loading ramps
- Powerful 24 V 300 Ah battery pack offers full 8 hour work shift
- Operator has choice of two lift speeds to suit applications
- Simple to drive with front-wheel drive zero inside turning radius for great maneuverability in narrow aisles tight spaces
- Four-wheel braking for responsive performance
- Swing-out battery box power module trays allow easy access to engine components for convenient service
